Mud Mixing Hopper Dia 708mm Solid Control Equipment Drilling

Brand Name : ATO

Model Number : ZHP150

Certification : API

Place of Origin : China

MOQ : 1sets

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10sets/month

Delivery Time : 30days

Packaging Details : Wooden

Type (kg) : ZHP150

Inlet Flow (m3/h) : 180

Inlet Head (m) : >31m

Hopper Diameter (mm) : 708

Inlet diameter : 125

Outlet Diameter : 150

Jet Speed (m/s) : 45

Mix Pump Power (kw) : 55

Weight (kg) : 185

Dimension L*W*H(mm) : 1518*780*780

Contact Now

ZHP Mixing Hopper, is a kind of direct injected mixing hopper is a direct injected mixer of additive material of drilling fluid. It is mainly used to mix drilling fluid and additives quickly to improve drilling fluid’s performance. It also can have shearing and hydration system with shear pump, We have two models with metric and British system.

Mud Mixing Hopper Dia 708mm Solid Control Equipment Drilling

Features:

Quick Feeding: Strong suction with high speed jet nozzle.
Strong Mixing Capability: Venturi tube in outlet
Easy Operation: Standard butterfly valve on inlet
Customize products with different repuqirements for customer
Raw materials are strictly tested,confirm to API standards

Strong professional team, find the most suitable products for customers

Customer -Focused, to provice reliable and efficient one-stop worry-free service
High quality pumps parts supplier

Mud Mixing Hopper Dia 708mm Solid Control Equipment Drilling

Specifications

Type (kg)

Inlet Flow (m3/h)

Inlet Head (m)

Hopper Diameter (mm)

Inlet diameter

Outlet Diameter

Jet Speed (m/s)

Mix Pump Power (kw)

Weight

(kg)

Dimension L*W*H(mm)

ZHP150

180

>31m

708

125

150

185

1518*780*780

ZHP150-5

180

>31m

708

150

18/5

1518*780*780

Our Advantage:
